36V MultiVolt™ Brushless 1-1/8" SDS Plus D-Handle Rotary Hammer | Metabo HPT DH3628DD

Model# DH3628DD

  • POWER: High impact energy of 2.3 ft-lbs & 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance
  • AUTO STOP: Set your time for repetitive drilling
  • ERGONOMIC: D-Handle makes drilling easier especially for overhead and downward drilling
  • BIT MOUNTING: One-push bit mounting makes changing out bits quick and easy
  • VERSATILITY: Powered by a 36V MultiVolt battery (included) or AC adapter (sold separately)

  • POWER: High impact energy of 2.3 ft-lbs & 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance
  • AUTO STOP: Set your time for repetitive drilling
  • ERGONOMIC: D-Handle makes drilling easier especially for overhead and downward drilling
  • BIT MOUNTING: One-push bit mounting makes changing out bits quick and easy
  • VERSATILITY: Powered by a 36V MultiVolt battery (included) or AC adapter (sold separately)

Features

AUTO STOP

Set your time for repetitive drilling

POWER

High impact energy of 2.3 ft-lbs and 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance

VERSATILITY

Powered by a 36V MultiVolt battery (included) or AC adapter (sold separately)

ERGONOMIC

D - Handle makes drilling easier especially for overhead and downward drilling

The 36V MultiVolt Brushless SDS Plus 1-1/8" Rotary Hammer (DH3628DD) offers corded performance with the convenience and versatility of a cordless tool. GO all day as its D-Handle ergonomic design makes drilling easier, especially for overhead and downward drilling. Work more efficiently with the auto stop feature that allows you to set times for repetitive drilling. Control you power with its two-speed setting function. Work safely as the Reactive Force Control (RFC) stops the motor before the entire tool jerks if the tool bit is suddenly overburdened during operation. Work cleaner and safer with the optional dust extractor (# 376971M).

The DH3628DD 36V Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer is part of the expanding MultiVolt System of power tools from Metabo HPT. It accepts any MultiVolt battery for extreme power and runtime and can also accept the unique AC Adapter (ET36A) to plug in for all day runtime, offering ultimate versatility and power on the GO. Also Available as tool body only model DH3628DDQ4


Features of the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer

  • POWER: High impact energy of 2.3 ft-lbs & 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance
  • AUTO STOP: Set your time for repetitive drilling
  • ERGONOMIC: D-Handle makes drilling easier especially for overhead and downward drilling
  • BIT MOUNTING: One-push bit mounting makes changing out bits quick and easy
  • ON-TOOL LED: Provides plenty of light in dark spaces
  • VERSATILITY: Powered by a 36V MultiVolt battery (included) or AC adapter (sold separately)
  • BRUSHLESS MOTOR TECHNOLOGY: For more run-time, increased power, extended durability with essentially no maintenance
  • 2-STEP SPEED CONTROL: For faster work
  • REACTIVE FORCE CONTROL: Senses the tool overload and stops rotation to ensure user safety and protect the tool motor and battery
  • 3 MODE SELECTOR: Hammer Drilling, Chipping and Drilling
  • DUST EXTRACTOR SYSTEM: Featuring cyclonic separation method and HEPA filter for improved workability
  • CLEANER AND SAFER ENVIRONMENT: Compatible with dust extractor attachment (376971) or Vacuums/Extractors (RP350DYH and RP3608DAQ4)
  • DEPTH GAUGE: Consistently drill to desired depth
  • LIGHTWEIGHT AND COMPACT: 8.8 lbs (with BSL36B18), 15.8"
  • INCLUDES: 18V/36V 4.0Ah MultiVolt battery, rapid charger, side handle, depth gauge, carry case
  • ALSO AVAILABLE: Tool body only DH3628DDQ4
  • TOOL CARD: Download the DH3628DD Tool Card

Included with the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer

  • 18V/36V MultiVolt Lithium Ion Slide Battery 8.0Ah/4.0Ah (372121M
  • Rapid Charger (UC18YSL3)
  • Side Handle (335273)
  • Depth Gauge (303709)
  • Carrying Case (378656)

Optional accessories for the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer

  • Dust Collection Extractor (376971M)
  • 18V/36V MultiVolt Lithium Ion Slide Battery 5.0Ah/2.5Ah (371751M)
  • 36V MultiVolt AC Adapter (ET36A)

Specifications

Volts 36V
Bit Shank SDS Plus
Motor Type Brushless
Power Source DC
Modes Hammer Drilling | Chipping | Drilling
No Load Speed 0-950 RPM
Impact Rate 0-4,300 RPM
Impact Energy        2.3 ft-lbs
Concrete Capacity 1-1/8"
Steel Capacity 1/2"
Wood Capacity 1-1/4"
Variable Speed Trigger
LED Light Equipped
Auto Stop Mode Equipped
Speed Control 2
Tool Length (w/ 36V 4.0Ah Battery)               17-9/32"
Tool Width               3.3"
Tool Height               9.1""
Weight (Tool Body Only) 6.4 lbs
Warranty 1-Year













Includes

  • 18V/36V MultiVolt Lithium Ion Slide Battery 8.0Ah/4.0Ah (372121M
  • Rapid Charger (UC18YSL3)
  • Side Handle (335273)
  • Depth Gauge (303709)
  • Carrying Case (378656)
Optional accessories for the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer
  • Dust Collection Extractor (376971M)
  • 18V/36V MultiVolt Lithium Ion Slide Battery 5.0Ah/2.5Ah (371751M)
  • 36V MultiVolt AC Adapter (ET36A)
