30 Degree 36V Cordless Paper Strip Framing Nailer | Metabo HPT NR3690DC

Model# NR3690DC

  • CORDLESS FREEDOM: Pneumatic power with 36V cordless freedom
  • FASTENERS: Accepts 30 degree clipped head  or offset round head collated nails from 2 Inch up to 3-1/2 inch in length and 0.113  to 0.131 inch in diameter
  • SPEED: Drive 3 nails per second
  • WARRANTY: Covered by Metabo HPT's Lifetime Lithium Ion Tool Warranty and two-year Lithium Ion battery warranty

  • CORDLESS FREEDOM: Pneumatic power with 36V cordless freedom
  • FASTENERS: Accepts 30 degree clipped head  or offset round head collated nails from 2 Inch up to 3-1/2 inch in length and 0.113  to 0.131 inch in diameter
  • SPEED: Drive 3 nails per second
  • WARRANTY: Covered by Metabo HPT's Lifetime Lithium Ion Tool Warranty and two-year Lithium Ion battery warranty

Features

PNEUMATIC-LIKE FEEL

The unique air spring drive system delivers similar performance as a pneumatic nailer

TOOL-LESS DEPTH ADJUSTMENT

Get a professional finish with varying materials with the tool-less depth of drive adjustment

POWER

Drives 900 Nails per charge using Metabo HPT's 2.5Ah MultiVolt battery (included) or 1,200 Nails with the 4.0Ah MultiVolt battery

FASTENERS

Accepts round head 30 degree paper strip collated nails from 2 Inch up to 3-1/2 inch in length and (0.113 to 0.131)

The 36V MultiVolt 3-1/2 Inch Cordless Paper Strip Framing Nailer (NR3690DC) is here to maximize efficiency on the jobsite, this cordless nailer allows for a productivity boost as you do not have to navigate long hoses around the jobsite. The Cordless Paper Strip Framing Nailer delivers a driving speed of 3 nails per second, increasing productivity and saving you valuable time.

Thanks to Metabo HPT’s unique Air Spring Drive System, this 36V Cordless Clipped Head Framing Nailer delivers a feel and performance similar to that of a pneumatic nailer. The pneumatic-like feel combined with the convenience and power of the MultiVolt battery allows you to work with this cordless nailer all day long, driving clipped or off-set nails from 2” up to 3-1/2” in length and 0.113” up to 0.131” in diameter. The included 2.5Ah MultiVolt battery also drives 900 nails per charge.

The Cordless Paper Framing Nailer is part of the expanding MultiVolt system of power tools from Metabo HPT. This nailer accepts any MultiVolt battery for extreme cordless power on the jobsite, and also accepts the unique 36V AC adapter to plug-in and work all day. This cordless Framing Nailer is backed by Metabo HPT’s Lifetime Lithium-Ion Tool body warranty and a 2-year Lithium-Ion battery warranty for peace of mind.

Metabo HPT has been rated as the Pro Preferred Brand for nailers for 7-years running (2014-2020) by Builder & Developer magazine, giving you the confidence that you have the right framing nailers for the job.


Features of the Cordless Paper Strip Framing Nailer
  • AWARD: Rated the Pro Preferred Nailer for 9 years running (2014 - 2022) by Builder and Developer Magazine
  • CORDLESS FREEDOM: Pneumatic power with 36V cordless freedom
  • DRIVES: Up to 900 nails per charge with the included 2.5Ah MultiVolt battery (371751M)
  • SPEED: Drive 3 nails per second
  • PNEUMATIC-LIKE FEEL: Thanks to the unique Air Spring Drive System
  • FASTENERS: Accepts 30 degree clipped head  or offset round head collated nails from 2 Inch up to 3-1/2 inch in length and 0.113  to 0.131 inch in diameter
  • APPLICATIONS: Ideal for all construction framing applications and is particularly useful for punch-out work or remodeling jobs without the need for a tank or hose
  • BRUSHLESS MOTOR: More run-time, increased power, and extended durability with essentially no maintenance
  • DEPTH ADJUSTMENT: Get a professional finish with varying materials with the tool-less depth of drive adjustment
  • ZERO RAMP UP: There is no refilling of the air tank required, so pull the trigger and tool will shoot the nail
  • SELECTIVE ACTUATION: Allows for quick changes between sequential and contact nailing with the flip of a switch
  • DRY-FIRE LOCKOUT: Dry-fire lockout prevents empty (dry) firing for assured nail placement
  • SIDE LOCK SWITCH: Prevent accidental firing for assured nail placement
  • PIVOTING HOOK: Keeps the tool within reach
  • COMFORT: Ergonomic soft grip handle for comfort
  • RECOMMENDED: Use Metabo HPT Nails for best results
  • WARRANTY: Covered by Metabo HPT's Lifetime Lithium Ion Tool Warranty and two-year Lithium Ion battery warranty
  • TOOL CARD: Download the NR3690DC Tool Card

Included with the Cordless Paper Strip Framing Nailer
  • 36V MultiVolt™ 2.5Ah battery (371751M / BSL36A18)
  • Rapid Charger with USB Port (UC18YSL3)
  • Carrying Bag (372294M)
  • 3mm Hex Wrench (943277)
  • 4mm Hex Wrench (944458)
  • Safety Glasses (875769)

Specifications

36V MultiVolt 30˚ Cordless Framing Nailer

NR3690DC

Volts

(V)

36

Battery Type

Li-Ion

Motor Type

Brushless



Applicable Nails

Diameter (In.)

.113 -.131

Length (In.)

2 - 3-1/2

Nail Capacity

47

Nails per Charge

(w. 36V 2.5Ah Battery)

900

Magazine Angle

30°

Driving Speed

Nails per second

3

Magazine Loading

Rear

Actuation

Selective

Dry Fire Lockout

Yes

Depth Adjustment

Tool-less

Jam Clearing

Open Nose

Battery Charge Indicator

On-Battery

Pivoting Hook

Yes















Includes

  • 36V MultiVolt 3-1/2” Paper Strip Cordless Framing Nailer – (NR3690DC)
  • 36V MultiVolt™ 2.5Ah battery (371751M)
  • Rapid Charger with USB Port (UC18YSL3)
  • Carrying Bag (372294M)
  • 3mm Hex Wrench (943277)
  • 4mm Hex Wrench (944458)
  • Safety Glasses (875769)
