36V MultiVolt™ Brushless 1-1/8" SDS Plus D-Handle Rotary Hammer (Tool Body Only)| Metabo HPT DH3628DDQ4

Model# DH3628DDQ4


  • TOOL BODY ONLY: Accepts any 18V/36V MultiVolt battery or AC Adapter (sold separately)
  • POWER: High impact energy of 2.3 ft-lbs & 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance
  • AUTO STOP: Set your time for repetitive drilling
  • ERGONOMIC: D-Handle makes drilling easier especially for overhead and downward drilling
  • BIT MOUNTING: One-push bit mounting makes changing out bits quick and easy


  • TOOL BODY ONLY: Accepts any 18V/36V MultiVolt battery or AC Adapter (sold separately)
  • POWER: High impact energy of 2.3 ft-lbs & 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance
  • AUTO STOP: Set your time for repetitive drilling
  • ERGONOMIC: D-Handle makes drilling easier especially for overhead and downward drilling
  • BIT MOUNTING: One-push bit mounting makes changing out bits quick and easy

Features

AUTO STOP

Set your time for repetitive drilling

POWER

High impact energy of 2.3 ft-lbs and 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance

VERSATILITY

Powered by a 36V MultiVolt battery (included) or AC adapter (sold separately)

ERGONOMIC

D - Handle makes drilling easier especially for overhead and downward drilling

The 36V MultiVolt Brushless SDS Plus 1-1/8" Rotary Hammer (DH3628DDQ4) offers corded performance with the convenience and versatility of a cordless tool. GO all day as its D-Handle ergonomic design makes drilling easier, especially for overhead and downward drilling. Work more efficiently with the auto stop feature that allows you to set times for repetitive drilling. Control you power with its two-speed setting function. Work safely as the Reactive Force Control (RFC) stops the motor before the entire tool jerks if the tool bit is suddenly overburdened during operation. Work cleaner and safer with the optional dust extractor (# 376971M).

The DH3628DDQ4 36V Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer is part of the expanding MultiVolt System of power tools from Metabo HPT. It accepts any MultiVolt battery (sold separately) for extreme power and runtime and can also accept the unique AC Adapter - model ET36A (sold separately) to plug in for all day runtime, offering ultimate versatility and power on the GO. Also available kitted with MultiVolt battery and charger -  model DH3628DD


Features of the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer

  • TOOL BODY ONLY: Accepts any 18V/36V MultiVolt battery or AC Adapter (sold separately)
  • POWER: High impact energy of 2.3 ft-lbs & 950 RPM / 4,300 BPM for high drilling speeds and great demolition performance
  • AUTO STOP: Set your time for repetitive drilling
  • ERGONOMIC: D-Handle makes drilling easier especially for overhead and downward drilling
  • BIT MOUNTING: One-push bit mounting makes changing out bits quick and easy
  • ON-TOOL LED: Provides plenty of light in dark spaces
  • BRUSHLESS MOTOR TECHNOLOGY: For more run-time, increased power, extended durability with essentially no maintenance
  • 2-STEP SPEED CONTROL: For faster work
  • REACTIVE FORCE CONTROL: Senses the tool overload and stops rotation to ensure user safety and protect the tool motor and battery
  • 3 MODE SELECTOR: Hammer Drilling, Chipping and Drilling
  • DUST EXTRACTOR SYSTEM: Featuring cyclonic separation method and HEPA filter for improved workability
  • CLEANER AND SAFER ENVIRONMENT: Compatible with dust extractor attachment (376971) or Vacuums/Extractors (RP350DYH and RP3608DAQ4)
  • DEPTH GAUGE: Consistently drill to desired depth
  • BRUSHLESS MOTOR TECHNOLOGY: For more run-time, increased power, extended durability with essentially no maintenance
  • LIGHTWEIGHT AND COMPACT: 8.8 LBS (with BSL36B18 / 372121M), 15.8"
  • INCLUDES: Side handle, depth gauge, carry case
  • ALSO AVAILABLE: Kitted version with 18V/36V MultiVolt Lithium Ion Slide Battery 4.0Ah/8.0Ah (372121M) and Rapid Charger (UC18YSL3) DH3628DD
  • TOOL CARD: Download the DH3628DDQ4 Tool Card
Included with the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer
  • Side Handle (335273)
  • Depth Gauge (303709)
  • Carrying Case (378656)
Optional accessories for the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer
  • Dust Collection Extractor (376971M)
  • 18V/36V MultiVolt Lithium Ion Slide Battery 2.5Ah/5.0Ah (371751M)
  • 18V/36V MultiVolt Lithium Ion Slide Battery 4.0Ah/8.0Ah (372121M)
  • 36V MultiVolt AC Adapter (ET36A)

Specifications

Volts 36V
Bit Shank SDS Plus
Motor Type Brushless
Power Source DC
Models Hammer Drilling | Chipping | Drilling
No Load Speed 0-950 RPM
Impact Rate 0-4,300 RPM
Impact Energy        2.3 Ft-lbs
Concrete Capacity 1-1/8"
Steel Capacity 1/2"
Wood Capacity 1-1/4"
Variable Speed Trigger
LED Light Equipped
Auto Stop Mode Equipped
Speed Control 2
Tool Length (w/ 36V 4.0Ah Battery)               17-9/32"
Tool Width               3.3"
Tool Height               9.1""
Weight (Tool Body Only) 6.4 lbs
Warranty 1-Year













Includes

  • Side Handle (335273)
  • Depth Gauge (303709)
  • Carrying Case (378656)
Optional accessories for the 36V MultiVolt Brushless SDS Plus 1-1/8" D-Handle Rotary Hammer
  • Dust Collection Extractor (376971M)
  • 18V/36V MultiVolt Lithium Ion Slide Battery 2.5Ah/5.0Ah (371751M)
  • 18V/36V MultiVolt Lithium Ion Slide Battery 4.0Ah/8.0Ah (372121M)
  • 36V MultiVolt AC Adapter (ET36A)
